Instagram Transition

The Instagram transition is an Expansion Transition where a small image in a grid expands to full screen. Similar to the Pinterest transition, but the outgoing page remains static without animation, and only the incoming page animates.

Demo

localhost:3000/instagram/gallery

Gallery

Tap any photo to view details

Loading demo...

UX Principles

When to use?

The Instagram transition is used for transitions from image-centric feeds to detail views.

Suitability by Content Relationship

콘텐츠 관계	적합성	설명
Unrelated content	❌	Not suitable as there's no connection point to expand from
Sibling relationship	⚠️	Could be considered for navigation between images in a grid
Hierarchical relationship	✅	Optimal for expanded views of the same content, like thumbnail→full view

Key Use Cases

Social media feeds: Transition from grid feed to post detail
Photo galleries: Zoom from small thumbnails to large images
Portfolios: From work grid to detail view
Product listings: From product grid to detail page

Why does it work this way?

Maintains focus: The outgoing page stays in place, making it clear where the user came from
Performance optimization: Animating only one page ensures smooth transitions
Natural expansion: The selected image naturally fills the screen
Context preservation: The background remains visible, preventing disorientation

Motion Design

Expansion process (Gallery → Detail):
1. Gallery page remains static (no animation)
2. Detail page expands from the selected image position
3. Scales up to fill the screen with clip-path
4. Eventually occupies the entire screen

Contraction process (Detail → Gallery):
1. Detail page remains static (no animation)
2. Gallery page appears while contracting to target image position
3. Smoothly appears with opacity and scale animation

Basic Usage

1. Configure Transition

import { Ssgoi } from '@ssgoi/react';
import { instagram } from '@ssgoi/react/view-transitions';

const config = {
  transitions: [
    {
      from: '/gallery',
      to: '/gallery/*',
      transition: instagram(),
      symmetric: true
    }
  ]
};

export default function App() {
  return (
    <Ssgoi config={config}>
      {/* App content */}
    </Ssgoi>
  );
}

2. Mark Elements

Use different data attributes for gallery and detail pages:

// Gallery page (3-column grid)
function Gallery() {
  return (
    <div className="grid grid-cols-3 gap-1">
      {items.map(item => (
        <Link
          key={item.id}
          to={`/gallery/${item.id}`}
          className="aspect-square"
        >
          <img
            src={item.image}
            alt={item.title}
            data-instagram-gallery-key={item.id}
            className="w-full h-full object-cover"
          />
        </Link>
      ))}
    </div>
  );
}

// Detail page
function PostDetail({ item }) {
  return (
    <div className="min-h-screen">
      <img
        src={item.image}
        alt={item.title}
        data-instagram-detail-key={item.id}
        className="w-full h-auto"
      />
      <div className="p-4">
        <p className="font-semibold">{item.likes} likes</p>
        <p className="mt-2">{item.caption}</p>
      </div>
    </div>
  );
}

Practical Examples

1. Instagram-Style Feed

Uniform 3-column grid:

// 3-column grid
function InstagramFeed() {
  return (
    <div className="grid grid-cols-3 gap-1">
      {posts.map((post) => (
        <div
          key={post.id}
          onClick={() => navigate(`/post/${post.id}`)}
          className="relative aspect-square cursor-pointer group"
        >
          <img
            src={post.image}
            alt={post.title}
            data-instagram-gallery-key={post.id}
            className="w-full h-full object-cover"
          />
          {/* Hover overlay */}
          <div className="absolute inset-0 bg-black/40 opacity-0
                          group-hover:opacity-100 transition-opacity
                          flex items-center justify-center">
            <span className="text-white font-semibold">
              ❤️ {post.likes.toLocaleString()}
            </span>
          </div>
        </div>
      ))}
    </div>
  );
}

// Post detail
function PostView({ post }) {
  return (
    <div className="min-h-screen bg-black">
      <img
        src={post.image}
        alt={post.title}
        data-instagram-detail-key={post.id}
        className="w-full h-auto"
      />

      {/* Post details */}
      <div className="bg-white p-4">
        <div className="flex items-center gap-4 mb-4">
          <button className="flex items-center gap-2">
            <HeartIcon className="w-6 h-6" />
            <span>{post.likes}</span>
          </button>
          <button>
            <CommentIcon className="w-6 h-6" />
          </button>
          <button>
            <ShareIcon className="w-6 h-6" />
          </button>
        </div>

        <p className="text-sm">
          <strong>{post.author}</strong> {post.caption}
        </p>

        <p className="text-xs text-gray-500 mt-2">
          {post.timestamp}
        </p>
      </div>
    </div>
  );
}

2. Photo Portfolio

From work grid to fullscreen:

// Portfolio grid
function PortfolioGrid() {
  return (
    <main className="container mx-auto p-4">
      <div className="grid grid-cols-3 gap-4">
        {works.map((work) => (
          <article
            key={work.id}
            onClick={() => navigate(`/work/${work.id}`)}
            className="relative aspect-square rounded-lg overflow-hidden
                       cursor-pointer hover:scale-105 transition-transform"
          >
            <img
              src={work.thumbnail}
              alt={work.title}
              data-instagram-gallery-key={work.id}
              className="w-full h-full object-cover"
            />
            <div className="absolute bottom-0 left-0 right-0 p-3
                            bg-gradient-to-t from-black/80 to-transparent">
              <h3 className="text-white font-semibold text-sm">
                {work.title}
              </h3>
              <p className="text-white/80 text-xs">{work.category}</p>
            </div>
          </article>
        ))}
      </div>
    </main>
  );
}

// Work detail
function WorkDetail({ work }) {
  return (
    <div className="min-h-screen bg-gray-900">
      <div className="max-w-4xl mx-auto">
        <img
          src={work.image}
          alt={work.title}
          data-instagram-detail-key={work.id}
          className="w-full h-auto"
        />

        <div className="p-6 text-white">
          <h1 className="text-3xl font-bold mb-2">{work.title}</h1>
          <p className="text-gray-400 mb-4">{work.category}</p>
          <p className="text-gray-300 leading-relaxed">
            {work.description}
          </p>

          <div className="mt-6 flex gap-4">
            <span className="text-sm text-gray-400">
              {work.date}
            </span>
            <span className="text-sm text-gray-400">
              {work.client}
            </span>
          </div>
        </div>
      </div>
    </div>
  );
}

Customization

Spring Configuration

Adjust animation elasticity and speed:

instagram({
  spring: {
    stiffness: 150,  // Lower for smoother animation
    damping: 20      // Higher for faster settling
  }
})

Precautions

Key Attribute Distinction

Gallery: data-instagram-gallery-key
Detail: data-instagram-detail-key
Must use different attribute names

Layout Considerations

Gallery should use uniform grid (3 columns recommended)
Detail page needs sufficient padding
Images should maintain aspect-ratio

Differences from Pinterest Transition

Pinterest: Both pages animate
Instagram: Only incoming page animates
Performance: Instagram is lighter and faster
Use case: Instagram is optimal for uniform grids

Accessibility

Support ESC key to close detail page
Enhanced keyboard navigation
Instant transition when motion is reduced

Best Practices

✅ DO

Use with uniform 3-column grids
Apply to image-centric content
Provide clear close button
Use mobile-optimized layout

❌ DON'T

Not suitable for irregular grids
Avoid with text-heavy content
Don't expand too many elements simultaneously
Be cautious with large images on slow networks
